Products Description
Dry Type / Eco-friendlyNo burning, no washing, no waste water, no toxic gas, fully meet environmental protection standards.
High Separation RateSeparation rate up to 99%, copper purity can reach 99%+.
High Efficiency /Energy SavingOne-key automatic operation, low power consumption, high output.
Wide Application Suitable for all kinds of scrap wires: car wires, communication cables, household wires, network cables, etc.
Double Profits Recycle high-purity copper granules and plastic granules at the same time.
Stable Performance Durable blades, low noise, easy operation and maintenance.
Small Occupation Compact structure, small floor space, suitable for small workshops and factories.
Technical Parameters
Model: Customizable
Capacity: 80–300 kg/h
Power: 15–55 kW
Voltage: 380V 50Hz 3P (can be customized)
Separation Rate: ≥99%
Copper Purity: ≥99%
Dimension: Customizable
Weight: 800–2500 kg
Working Type: Dry type
Hot Tags: copper plastic separating machine, China copper plastic separating machine manufacturers, suppliers
|
Model |
YZT200 |
YZT260 |
YZT280 |
YZT400 |
|
Voltage |
220v/380V /50Hz/60Hz |
220v/380V /50Hz/60Hz |
220v/380V /50Hz/60Hz |
220v/380V /50Hz/60Hz |
|
Power |
3.9 KW |
5.75 KW |
5.68 KW |
8.68 KW |
|
Output |
30-50KG/H |
50-80KG/H |
50-80KG/H |
100-180KG/H |
|
Shredding cable diameter range |
1-25MM |
1-30MM |
1-30MM |
1-35MM |
|
Copper mill cabinet material |
Carbon steel |
|||
|
Tool size |
150*58*16MM 150*50*16 |
200*58*16MM 200*50*16 |
200*58*16MM 200*50*16 |
154*85*16MM 300*70*16 |
|
Feed opening size |
275*220MM |
280*195MM |
325*230MM |
435*275mm |
|
Feed opening height from the ground |
1460mm |
1600mm |
1532MM |
1650MM |
|
Output opening width |
420MM |
135MM |
380MM |
450MM |
|
Copper outlet width Product size |
470MM |
135MM |
450MM |
585MM |
|
Product size |
83*55.5*159CM |
100*62*185CM |
103*58*179CM |
105*133*194cm |
